ETA C: Refinitiv Real-Time Optimized Version 2 Authentication Migration Guide

February 09,2023

Author:

Jirapongse Phuriphanvichai

Real-Time Optimized (RTO) is Refinitiv conflated real-time content, hosted in the public cloud. It provides fast and simple access to our unparalleled content from hundreds of exchanges and OTC markets around the world.

With the RDP version 1 authentication, to connect to Refinitiv Real-Time Optimized, Refinitiv Real-Time applications need to send credentials to the authentication service on the Refinitiv Data Platform (RDP) to get an access token and a refresh token. An access token is a short live token used to log in to the Refinitiv Real-Time Optimized server while a refresh token is a long live token used to renew an access token. Therefore, the application needs to periodically use a refresh token to renew an access token and then use a new access token to re-login to the Refinitiv Real-Time Optimized server. Otherwise, the server will cut a connection when an access token expired. Moreover, a credential can’t be used simultaneously because a refresh token will be invalidated when the same credential is used by other applications. Then, the application with the invalid refresh token can’t renew an access token.

The new RDP version 2 authentication simplifies the usage of access tokens. RDP version 2 authentication will only generate an access token, not both access and refresh tokens. Once connected to the Refinitiv Real-Time Optimized with an access token, there is no need to renew the access Token. The login session will remain valid until the application disconnects or is disconnected from RTO.

This article provides guidelines to migrate the ETA C consumer applications to use RDP version 2 authentication. RTSDK 2.0.5.L1 (ETA 3.6.5.L1) and above support RDP version 2 authentication.

RDP Version 2 Authentication Code Migration

ETA C applications use the Enterprise Transport API reactor to connect to Refinitiv Real-Time Optimized. The Enterprise Transport API reactor is a connection management and event processing component that can significantly reduce the amount of code an application must write. The following parts in the code must be modified to migrate the ETA C applications to use RDP version 2 authentication.

Note: This article covers RDP Version2 Authentication Service Credentials which ServiceID and password are clientId and clientSecret, respectively.

1. Setting RDP version 2 authentication credentials in the OMM consumer role

RDP version 2 authentication oAuth Client Credentials requires a client ID and client secret instead of a username, password, and client ID. The client ID in version 2 is different from the client ID in version 1.

The client ID and client secret are set in the RsslReactorOAuthCredential instance.


            typedef struct
{
       RsslBuffer    userName;
       RsslBuffer    password;
       RsslBuffer    clientId;
       RsslBuffer    clientSecret;
       RsslBuffer    tokenScope;
       RsslReactorOAuthCredentialEventCallback  *pOAuthCredentialEventCallback;
       RsslBool      takeExclusiveSignOnControl;
       void*        userSpecPtr;
} RsslReactorOAuthCredential;

The code must be modified to use the client ID and client secret, as shown below.


            RsslBuffer clientId = RSSL_INIT_BUFFER;
RsslBuffer clientSecret = RSSL_INIT_BUFFER;

RsslReactorOAuthCredential oAuthCredential;
rsslClearReactorOAuthCredential(&oAuthCredential);

clientId.data = "<client id>";
clientId.length = strlen(clientId.data);

clientSecret.data = "<client secret>";
clientSecret.length = strlen(clientSecret.data);

oAuthCredential.clientId = clientId;
oAuthCredential.clientSecret = clientSecret;

Note: The userName, password, and takeExclusiveSignOnControl properties are not used in RDP version 2 authentication.

Then, the RsslReactorOAuthCredential is assigned to the pOAuthCredential or pOAuthCredentialList in the RsslReactorOMMConsumerRole.


            typedef struct
{
…
       RsslReactorOAuthCredential*  pOAuthCredential;
       RsslReactorOAuthCredential** pOAuthCredentialList;
…
} RsslReactorOMMConsumerRole;

2. Setting RDP version 2 authentication credentials in the service discovery

If the application uses the service discovery, this modification is required.

The service discovery is used to query service endpoints from the Refinitiv Real-Time Optimized service. It also requires RDP credentials to connect to the service discovery endpoint. To migrate to RDP version 2 authentication, the client ID and client secret must be set in the RsslReactorServiceDiscoveryOptions instance.


            typedef struct
{
…
       RsslBuffer    clientId;
       RsslBuffer    clientSecret;
…
} RsslReactorServiceDiscoveryOptions;

The code must be modified to use the client ID and client secret, as shown below.


            RsslBuffer clientId = RSSL_INIT_BUFFER;
RsslBuffer clientSecret = RSSL_INIT_BUFFER;

RsslReactorServiceDiscoveryOptions serviceDiscoveryOpts;
rsslClearReactorServiceDiscoveryOptions(&serviceDiscoveryOpts);

clientId.data = "<client id>";
clientId.length = strlen(clientId.data);

clientSecret.data = "<client secret>";
clientSecret.length = strlen(clientSecret.data);

serviceDiscoveryOpts.clientId = clientId;
serviceDiscoveryOpts.clientSecret = clientSecret;
...

Note: The userName, password, and takeExclusiveSignOnControl properties are not used in RDP version 2 authentication.

Then, RsslReactorServiceDiscoveryOptions is passed to the rsslReactorQueryServiceDiscovery method.


            if(rsslReactorQueryServiceDiscovery(pReactor, &serviceDiscoveryOpts, &rsslErrorInfo) != RSSL_RET_SUCCESS)
{
       printf("Error: %s\n", rsslErrorInfo.rsslError.text);
       exit(-1);
}

3. Setting a client secret in the RsslReactorOAuthCredentialRenewal

If the application uses the OAuth credential event callback function, this modification is required.

If pOAuthCredentialEventCallback is specified in the RsslReactorOAuthCredential, the Value Added Components Reactor does not store the password or clientSecret. In this case, the application must supply the password or clientSecret whenever the OAuth credential event callback function is invoked.


            typedef struct
{
       RsslBuffer    userName;
       RsslBuffer    password;
       RsslBuffer    clientId;
       RsslBuffer    clientSecret;
       RsslBuffer    tokenScope;
       RsslReactorOAuthCredentialEventCallback  *pOAuthCredentialEventCallback;
       RsslBool      takeExclusiveSignOnControl;
       void*        userSpecPtr;
} RsslReactorOAuthCredential;

In the callback function, the client secret is set in the RsslReactorOAuthCredentialRenewal instance and then is passed to the rsslReactorSubmitOAuthCredentialRenewal method.


            RsslBuffer clientSecret = RSSL_INIT_BUFFER;

clientSecret.data = "<client secret>";
clientSecret.length = strlen(clientSecret.data);
…
…

RsslReactorCallbackRet oAuthCredentialEventCallback(RsslReactor *pReactor, RsslReactorOAuthCredentialEvent* pOAuthCredentialEvent)
{
       RsslReactorOAuthCredentialRenewalOptions renewalOptions;
       RsslReactorOAuthCredentialRenewal reactorOAuthCredentialRenewal;
       RsslErrorInfo rsslError;
       rsslClearReactorOAuthCredentialRenewalOptions(&renewalOptions);
       renewalOptions.renewalMode = RSSL_ROC_RT_RENEW_TOKEN_WITH_PASSWORD;

       rsslClearReactorOAuthCredentialRenewal(&reactorOAuthCredentialRenewal);

       reactorOAuthCredentialRenewal.clientSecret = clientSecret;

       rsslReactorSubmitOAuthCredentialRenewal(pReactor, &renewalOptions, &reactorOAuthCredentialRenewal, &rsslError);

       return RSSL_RC_CRET_SUCCESS;
}

4. Changing the RDP version 2 authentication endpoint

If the application changes the endpoint of the RDP authentication service, this modification is required.

By default, the endpoint of the RDP version 2 authentication is https://api.refinitiv.com/auth/oauth2/v2/token. However, this can be overridden by specifying another endpoint in the tokenServiceURL_V2 property of the RsslCreateReactorOptions instance.


            typedef struct {
...
       RsslBuffer    tokenServiceURL_V2;
...
} RsslCreateReactorOptions;

The RDP version 2 authentication endpoint can be changed via the following code.


            RsslBuffer tokenURLV2 = RSSL_INIT_BUFFER;

RsslCreateReactorOptions   reactorOpts;
rsslClearCreateReactorOptions(&reactorOpts);
...
tokenURLV2.data = "<RDP V2 Authentication Endpoint>";
tokenURLV2.length = strlen(tokenURLV2.data);
reactorOpts.tokenServiceURL_V2 = tokenURLV2;
...

Then, the RsslCreateReactorOptions is passed to the rsslCreateReactor method.


            RsslReactor   *pReactor
...

if (!(pReactor = rsslCreateReactor(&reactorOpts, &rsslErrorInfo)))
{
       printf("Error: %s", rsslErrorInfo.rsslError.text);
       exit(-1);
}

For more information, please refer to the VAConsumer, WatchistConsumer, and MultiCredWLConsumer examples in the Refinitiv Real-Time SDK Cpp-C package.

Summary

RDP version 2 authentication simplifies the usage of access tokens when connecting to Refinitiv Real-Time Optimized. It uses a client ID, and client secret instead of a username, password, and client ID (application key). The applications don’t need to renew access tokens at every specific interval. The access token used by the application will remain valid until the application disconnects or is disconnected from Refinitiv Real-Time Optimized. To migrate applications to use RDP version 2 authentication, the code that relates to RDP Authentication must be modified including setting a client ID and client secret in RsslReactorOAuthCredential, RsslReactorServiceDiscoveryOptions, and RsslReactorOAuthCredentialRenewal, and changing the RDP version 2 authentication endpoint in RsslCreateReactorOptions.
